THS/PH21N-FFV

THS/PH21N-FFV

For granular and powder products

The THS/PH21N-FFV is a specialized powder inspection Metal Detector that combines a compact footprint with the high sensitivity of the THS/PH21N series. Entirely constructed from AISI 316L stainless steel, it integrates perfectly into production lines with limited space while maintaining high-quality inspection standards. Versatility is guaranteed by the ATEX Zone 21 version, specifically designed for explosive atmospheres related to powder handling. It includes built-in AUTOTEST and AUTO-QC functions for operational safety and pharmaceutical compliance, with the option to request a UL/CSA certified Control Power Box.

Request For Information

Key Points

Ultra High Sensitivity to all metals

Very compact size

AISI 316L stainless steel construction

Control Power Box available according to UL 508A and CSA-C22.2 No. 286

ATEX ZONE 21 version (available on demand)

AUTOTEST function

AUTO-QC function

Ultra-High Sensitivity in Compact Dimensions

The THS/PH21N-FFV represents the ideal solution for inspecting powders and granules in production lines where installation space is extremely limited. Despite its minimal footprint, the system maintains the ultra-high sensitivity typical of the THS/PH21N series, ensuring accurate interception of all magnetic, non-magnetic, and stainless steel metals. This combination of compactness and precision makes it an essential component for ensuring product quality even in the most crowded plant configurations.

Engineering and Safety for ATEX Environments

Constructed entirely with an AISI 316L stainless steel structure and components, the system is designed to withstand harsh industrial environments and ensure maximum hygiene. A distinctive feature of the THS/PH21N-FFV is its availability in an ATEX Zone 21 version, allowing for safe installation in potentially explosive atmospheres due to the presence of combustible dust. Electrical safety is further certified by the Control Power Box, available in compliance with international UL 508A and CSA-C22.2 No. 286 standards.

Superior Rejection System and Hygiene

The integration of the rejection valve is specifically designed for the pharmaceutical and food sectors. The valve design allows for rapid assembly and disassembly without the use of tools, facilitating cleaning operations and preventing cross-contamination. The airtight seal of the rejection system ensures that the product flow remains protected from the external environment and that dust is not dispersed during the contaminant expulsion phases.

Quality Control Automation

To ensure consistent and documentable performance, the THS/PH21N-FFV integrates advanced AUTOTEST and AUTO-QC functions. The AUTOTEST function performs continuous automatic monitoring of vital system parameters, while AUTO-QC (Quality Control) simplifies periodic sensitivity verification procedures for the operator. These tools drastically reduce downtime and ensure that the metal detector always operates at the highest level of efficiency, in full compliance with corporate quality management protocols.

Traceability and Data Integrity

In line with the needs of modern production facilities, the system supports compliance with FDA 21 CFR Part 11 regulations. Thanks to the secure management of electronic records and the capacity to store a high number of events, the THS/PH21N-FFV ensures total and transparent traceability. Connectivity to external systems allows for the export of production reports and the integration of inspection data into management systems (ERP/SCADA), transforming safety into a strategic asset for the company.
